Cabinet Installed Frequency Drive Inverter with Multi Motor Switchover for Precise Control
Cabinet Installed Frequency Drive Inverter Product Description:
Equipped with a built-in PID, the VFD easily forms a closed-loop control system, ensuring stable and accurate control over the motor's speed and torque. With this feature, the VFD is capable of controlling the motor's speed based on feedback from an external device, such as a sensor or encoder, thus enabling precise control over the motor's speed and position.
The VFD also features automatic voltage regulation (AVR), which automatically keeps the output voltage constant when the grid voltage varies within a certain range, ensuring stable operation and protecting the motor from damage due to voltage fluctuations. This feature also helps to prolong the motor's lifespan, reducing maintenance and replacement costs.
In vector control mode, the VFD has a torque pulsation of ≤±5%, which ensures smooth and stable operation of the motor, even at low speeds. This makes it ideal for applications that require precise control over the motor's speed and torque, such as in manufacturing, automation, and HVAC systems.
The closed-loop vector VFD inverter is an essential component in many industrial applications, and the Frequency Drive Inverter is an excellent choice for those looking for a high-quality, reliable, and efficient VFD. Whether you need precise control over the motor's speed and torque or require stable operation in harsh environments, the VFD has all the features you need to get the job done.
Cabinet Installed Frequency Drive Inverter Features:
- Product Name: Frequency Drive Inverter
- Overload capacity:G-model: 150% 1min/5min, 180% 3s/5min, P-model: 110% 1min/5min, 150% 3s/5min
- Speed range:1:10 V/F, 1:100 OLVC, 1:1000 CLVC
- Number of phases: Three Phase
- Torque response: ≤ 5ms, In Vector Control Mode
- Input power frequency: (50Hz/60Hz)±5%
- Features: Closed-loop vector VFD inverter,Vector Inverter, Vector Converter
Cabinet Installed Frequency Drive Inverter Technical Parameters:
| Technical Parameter | Description |
| Product Name | Frequency Drive Inverter |
| Topology | Two Quadrants |
| Overload Capacity | G-model: 150% 1min/5min, 180% 3s/5min
P-model: 110% 1min/5min, 150% 3s/5min |
| Storage Temperature | −40℃-+70℃ |
| Power Class | 7.5kW (heavy Load), 11kW (light Load)/15kW (heavy Load), 18.5kW (light Load) |
| Cooling Method | Air Cooling |
| Built-in PID | Easily Forms A Closed-loop Control System |
| Multi-motor Switchover | With 2 Sets Of Motor Parameters, The Switchover Between 2 Motors Can Be Realized |
| Automatic Voltage Regulation (AVR) | Automatically Keeps The Output Voltage Constant When Grid Voltage Varies Within A Certain Range |
| Input Power Frequency | (50Hz/60Hz)±5% |
| Acceleration/Deceleration Curves | Straight-line, S-curve |
| Description | Closed-loop vector VFD inverter, suitable for heavy and light loads. |
Cabinet Installed Frequency Drive Inverter Applications:
The HV510 has an input power frequency of (50Hz/60Hz)±5%, making it suitable for use in various countries. It has a torque response of ≤ 5ms in Vector Control Mode, ensuring quick and accurate control of the motor. The speed stability of the HV510 is also impressive, with OLVC at 0.2% and CLVC at 0.1%. The power class of the HV510 is 7.5kW (heavy Load), 11kW (light Load)/15kW (heavy Load), and 18.5kW (light Load), providing options for various load requirements. The acceleration/deceleration curves of the HV510 include Straight-line and S-curve, making it versatile for use in different scenarios.
The HV510 is an open-loop vector VFD inverter that can be used in various industries, including but not limited to, textile, printing, packaging, and food processing. It is ideal for applications requiring high torque and high precision control, making it suitable for use in conveyor systems, pumps, compressors, and other machinery.
In summary, the HV510 is a high-quality vector converter that is versatile and reliable. It is ideal for various applications and industries and is readily available with a minimum order quantity of 1. With its impressive features and certifications, the HV510 is a top choice for customers looking for a high-quality vector inverter.
Cabinet Installed Frequency Drive Inverter Support and Services:
Our Frequency Drive Inverter product comes with a comprehensive technical support and services package to ensure that our customers get the most out of their investment. Our team of experienced technical experts is available to assist with installation, configuration, and troubleshooting. In addition, we offer training and educational resources to help our customers better understand the product and its capabilities. Our services also include maintenance and repair, as well as upgrades and customization to suit specific needs. We are committed to providing excellent customer service and support for our Frequency Drive Inverter product.
